EdgeMaxTM EM180

  • Frequency Response (+/-3 dB)
    50 Hz – 18 kHz
  • Frequency Range (-10 dB)
    45 Hz – 20 kHz
  • Nominal Dispersion
    75° Vertical &180° Horizontal
  • Long-Term Power Handling
    125 W (500 W peak)
  • Sensitivity (SPL / 1 W @ 1 m)
    93 dB SPL
  • Maximum SPL @ 1 m
    114 dB SPL (120 dB SPL peak)

EdgeMaxTM EM90

  • Frequency Response (+/-3 dB)
    50 Hz – 18 kHz
  • Frequency Range (-10 dB)
    45 Hz – 20 kHz
  • Nominal Dispersion
    75° Vertical & 90° Horizontal
  • Long-Term Power Handling
    125 W (500 W peak)
  • Sensitivity (SPL / 1 W @ 1 m)
    96 dB SPL
  • Maximum SPL @ 1 m
    117 dB SPL (123 dB SPL peak)
  • Transducers
    1 x 8-inch woofer & 1 x compression driver

FreeSpace DS 16S

  • Frequency Response (+/-3 dB)
    95 Hz – 17 kHz
  • Frequency Range (-10 dB)
    80 Hz – 19 kHz
  • Nominal Dispersion
    170° H x 160° V
  • Long-Term Power Handling
    16 W (64 W peak)
  • Sensitivity (SPL / 1 W @ 1 m)
    84 dB SPL
  • Maximum SPL @ 1 m
    96 dB SPL (102 dB SPL peak)

FreeSpace DS 16SE

  • Frequency Response (+/-3 dB)
    95 Hz – 17 kHz
  • Frequency Range (-10 dB)
    80 Hz – 19 kHz
  • Nominal Dispersion
    170° H x 160° V
  • Long-Term Power Handling
    16 W (64 W peak)
  • Sensitivity (SPL / 1 W @ 1 m)
    84 dB SPL
  • Maximum SPL @ 1 m
    96 dB SPL (102 dB SPL peak)
  • Nominal Impedance
    8 Ω (transformer bypassed)

FreeSpace 3 Flush-Mount Satellites

  • Frequency Response (+/-3 dB)
    50 Hz – 16 kHz (System) & 210 Hz – 16 kHz (Satellites)
  • Frequency Range (-10 dB)
    40 Hz – 20 kHz (System) & 170 Hz – 20 kH z (Satellites)
  • Nominal Dispersion
    170 ° conical
  • Long-Term Power Handling
    System: 70/100 V: 200 W (800 W peak), System Low impedance: 100 W (400 W peak), Satellites: 12W (48W Peak)

FreeSpace 3 Surface-Mount Satellites

  • Frequency Response (+/-3 dB)
    50 Hz – 16 kHz (System) & 210 Hz – 16 kHz (Satellites)
  • Frequency Range (-10 dB)
    40 Hz – 20 kHz (System) &170 Hz – 20 kH z (Satellites)
  • Nominal Dispersion
    170 ° conical
  • Long-Term Power Handling
    System: 70/100 V: 200 W (800 W peak), System Low impedance: 100 W (400 W peak) & Satellites: 12W (48W Peak)

FreeSpace DS 100F

  • Frequency Response (+/-3 dB)
    75 Hz – 18 kHz
  • Frequency Range (-10 dB)
    60 Hz – 20 kHz
  • Nominal Dispersion
    160° conical
  • Long-Term Power Handling
    100 W (400 W peak)

FreeSpace 3 Series I Acoustimass bass module

  • Frequency Response (+/-3 dB)
    50 Hz – 230 Hz
  • Frequency Range (-10 dB)
    40 Hz – 315 Hz
  • Nominal Dispersion
    Omni-directional below 200 Hz
  • Long-Term Power Handling
    70/100 V: 200 W (800 W peak) mono
    Low impedance: 50 W (200 W peak) per channel stereo or 100 W (400 W peak) mono

FreeSpace 3 Series II Acoustimass

  • Frequency Response (+/-3 dB)
    50 Hz – 230 kHz
  • Frequency Range (-10 dB)
    40 Hz – 315 Hz
  • Nominal Dispersion
    Omni-directional below 200 Hz
  • Long-Term Power Handling
    70/100 V: 200 W (800 W peak) mono
    Low impedance: 50 W (200 W peak) per channel stereo or 100 W (400 W peak) mono

Powermatch

PowerMatch PM8500 / PM8500N power amplifier

  • Maximum Rated Power
    4000 W (500 W x 8 channels at 4 ohms)
  • Input Channels
    8 (balanced line level)
  • Output Channels
    2 to 8 (configurable)

PowerMatch PM8250 / PM8250N power amplifier

  • Maximum Rated Power
    2000 W (250 W x 8 channels at 4 ohms)
  • Input Channels
    8 (balanced line level)
  • Output Channels
    2 to 8 (configurable)

PowerMatch PM4500 / PM4500N power amplifier

  • Maximum Rated Power
    2000 W (500 W x 4 channels at 4 ohms)
  • Input Channels
    4 (balanced line level)
  • Output Channels
    1 to 4 (configurable)

PowerMatch PM4250 / PM4250N power amplifier

  • Maximum Rated Power
    1000 W (250 W x 4 channels at 4 ohms)
  • Input Channels
    4 (balanced line level)
  • Output Channels
    1 to 4 (configurable)

Powershare

PowerShare PS602 adaptable power amplifier

  • Amplifier power
    2 x 300 W
  • Maximum power per channel
    600 W @ 4-8 Ω, 70/100V
  • Input channels
    2 unbalanced, 2 balanced
  • 2 outputs

PowerShare PS602P adaptable power amplifier

  • An adaptable power amplifier delivers 600 watts for
    portable applications. Through patented technology, total amplifier power is shared across all output channels, allowing installers the freedom to utilize power where needed. With support for both low- and high-impedance loads up to 100V.

PowerShare PS604D Adaptable Power Amplifier

  • Amplifier Power
    4 x 150W (THD+N < 0.04%, 1 kHZ, 4-8 Ω, 70/100V)
  • Input Channels
    Analog: 4 balanced & Dante: 4 Digital
  • Maximum Power
    600 W @ 4-8 Ω, 70/100 V
  • Output Channels
    Analog: 4

PowerShare PS604A Adaptable Power Amplifier

  • Amplifier Power
    4 x 150 W (THD+N < 0.04%, 1 kHz, 4-8 Ω, 70/100V)
  • Maximum power per channel
    600 W @ 4-8 Ω, 70/100V
  • Input channels
    Analog: 4 balanced & AmpLink: 24 digital
  • Outputs
    Analog: 4 & AmpLink: 24 digital

Freespace

FreeSpace DXA 2120

  • Amplifier Power
    2 x 120 W at 4 ohms , 2 x 65 W at 8 ohms, or 2 x 100 W at 70/100V
  • Signal-to-Noise Ratio
    75 dB (below rated power, A-weighted)
  • THD
    ≤0.5 % (at full rated power)
  • Dynamic Range
    80 dB
  • Output Channels
    2 channels

FreeSpace IZA 2120-HZ

  • Frequency Response
    55 Hz – 20 kHz (+0/–3 dB, @ 1 W reference 1 kHz)
  • Amplifier Power
    2 x 120 W @ 70/100V
  • THD+N
    ≤ 0.3 % (at rated power)
  • Dynamic Range
    88 dB
  • Built-in Loudspeaker EQ
    Bose FreeSpace® 3 systems, FS3 subwoofer, DS 16, DS 40 and DS 100

FreeSpace IZA 2120-LZ

  • Frequency Response
    20 Hz – 20 kHz (+0/–3 dB, @ 1 W reference 1 kHz)
  • Amplifier Power
    2 x 120 W @ 4 Ω, 2 x 60 W @ 8 Ω
  • THD+N
    ≤ 0.5 % (at rated power)
  • Dynamic Range
    88 dB
  • Built-in Loudspeaker EQ
    Bose FreeSpace® 3 systems, FS3 subwoofer, DS 16, DS 40 and DS 100

FreeSpace ZA 2120-HZA Zone Amplifier

  • THD+N
    ≤ 0.3 % (at rated power)
  • Amplifier Power
    2 x 120 W @ 70/100V
  • Frequency Response
    55 Hz – 20 kHz (+0/–3 dB, @ 1 W reference 1 kHz)
  • Dynamic Range
    88 dB
  • Input Channels
    Analog: 1 unbalanced, 1 balanced & AmpLink: 8 digital

FreeSpace ZA 2120-LZA Zone Amplifier

  • THD+N
    ≤ 0.5 % (at rated power)
  • Amplifier Power
    2 x 120 W @ 4 Ω, 2 x 60 W @ 8 Ω
  • Frequency Response
    20 Hz – 20 kHz (+0/–3 dB, @ 1 W reference 1 kHz)
  • Dynamic Range
    88 dB
  • Input Channels
    Analog: 1 unbalanced, 1 balanced & AmpLink: 8 digital

FreeSpace IZA 250-LZ

  • Amplifier Power
    2 x 50 W @ 4 Ω, 2 x 25 W @ 8 Ω
  • Frequency Response
    40 Hz – 20 kHz (+0/-3 dB, @ 1 W reference 1 kHz)
  • THD+N
    ≤0.3 % (at full rated power)
  • Dynamic Range
    88 dB
  • Built-in Loudspeaker EQ
    Bose FreeSpace DS 16 or DS 40, No EQ

FreeSpace ZA 250-LZ

  • Amplifier Power
    2 x 50 W @ 4 Ω, 2 x 25 W @ 8 Ω & 1 x 90 W @ 70/100 V
  • Frequency Response
    20 Hz – 20 kHz (+0/-3 dB, @ 1 W reference 1 kHz)
  • THD+N
    ≤0.3 % (at full rated power)
  • Dynamic Range
    88 dB

FreeSpace IZA 190-HZ

  • Amplifier Power
    1 x 90W @ 70/100V
  • Frequency Response
    60 Hz – 20 kHz (+0/-3 dB, @ 1 W reference 1 kHz)
  • THD+N
    ≤1 % (at full rated power)
  • Dynamic Range
    88 dB
  • Built-in Loudspeaker EQ
    Bose FreeSpace DS 16 or DS 40, No EQ

ControlSpace ESP-00 Series II

  • Signal Processor
    Four 32-bit floating-point digital signal processors, 200 MHz
  • Sample Rate
    48 kHz
  • PC Configuration Software
    ControlSpace® Designer™ software
  • Expansion Slots
    8 analog/digital audio, 2 GPIO (1 occupied)
  • Audio Channel Capacity
    64 (bi-directional, digital and/or analog)

ControlSpace ESP-4120

  • Signal Processor
    32-bit fixed/floating-point DSP + ARM, 456 MHz
  • Dynamic Range
    > 115 dB, A-weighted 20 Hz – 20 kHz, analog through
  • Input Channels
    4 analog (balanced, mic/line level), 16 digital (via optional card)
  • Output Channels
    12 analog (balanced, line level), 8 ESPLink, 16 digital (via optional card)

ControlSpace ESP-1240

  • Signal Processor
    32-bit fixed/floating-point DSP + ARM, 456 MHz
  • Dynamic Range
    > 115 dB, A-weighted 20 Hz – 20 kHz, analog through
  • Input Channels 12 analog (balanced, mic/line level), 16 digital (via option card)
  • Output Channels
    4 analog (balanced, line level), 8 ESPLink, 16 digital (via optional card)

ControlSpace SP-24

  • Dynamic Range
    107 dB (typical)
  • Sample Rate
    48 kHz
  • Input Channels
    2 channels
  • Output Channels
    4 channels

Control Space ESP-1240AD engineered sound processor

  • Signal Processor
    32-bit fixed/floating-point DSP + ARM, 456 MHz
  • Input Channels
    12 analog (balanced, mic/line level), 32 via Dante
  • PC Configuration Software
    ControlSpace Designer software
  • Dynamic Range
    > 115 dB A-weighted 20 Hz – 20 kHz, analog through

Control Space ESP-1240A engineered sound processor

  • Signal Processor
    32-bit fixed/floating-point DSP + ARM, 456 MHz
  • Input Channels
    12 analog (balanced, mic/line level)
  • PC Configuration Software
    ControlSpace Designer software
  • Dynamic Range
    > 115 dB A-weighted 20 Hz – 20 kHz, analog through
